DESIGN FEATURES
Standard three-piece construction
Optional 50- or 100-mesh strainer (please refer to the Accessories PDF for more information)
Interchangeable spray tips
HOW SPRAY PATTERN IS ACHIEVED
A hollow cone nozzle sprays fluids in a ring-like pattern around a given radius and the spray exits on the same axis it enters in the axial design
For a full cone nozzle, atomization is achieved by the water being spun inside the nozzle and exiting an orifice
An insert is used to create the spray pattern
Produces medium to coarse droplet size
More uniform pattern than spiral nozzles
Available Spray Angles
80 - 120°
Flow Rate Range
0.0937 to 2.14 gpm
Available Connection Types
- Pipe: 1/8, 1/4, 3/8
- Connection Methods: Thread (NPT, BSP, Male, Female)
Materials
Brass, 303, 316
Flow Rates, Spray Angles, Connections
Full Cone
选择一个喷嘴数量低于性能图, drawings, and to request a quote.
Flow rate (gpm/lpm) is calculated at differential pressure (psi/bar).
Nozzle Number
Connection Sizes
Spray Angles
Flow Rate (gpm) @ Differential Pressure (psi) (Density: 1 SG)
10 psi
20 psi
40 psi
100 psi
200 psi
400 psi
Hollow Cone
选择一个喷嘴数量低于性能图, drawings, and to request a quote.
Flow rate (gpm/lpm) is calculated at differential pressure (psi/bar).
Nozzle Number
Connection Sizes
Spray Angles
Flow Rate (gpm) @ Differential Pressure (psi) (Density: 1 SG)
10 psi
20 psi
40 psi
100 psi
200 psi
400 psi
